In industrial applications, it is not uncommon that it is necessary to detect the weight of very large objects. The solution needed in these cases is constituted by the weighing platforms, systems where the platform supports the object to be weighed and transmits its load to the cells below, that measure synchronously to provide the precise value. In this way, the weighing platforms work like huge scales, with all the precision and robustness required by their use and by the loads which have to manage.
  |
SERIE BK Up to 800 tonnes/h, down to 0,1% inaccuracy Belt width 500 - 1300 mm Uses strain gauge load cells Easy to install with a minimum of modifications to the conveyor
|
  |
iFORKS Mobile Weighing Forks Tested on 1,000,000 cycles at 125% capacity Efficent energy control Data transfer via Bluetooth Maximum overload 200% of rated capacity
|
|
|
WLL Stainless Steel Telemetry Load Link Ratings from 5 to 100te Stainless steel construction (17-4PH H900) Environmentally sealed to IP67 Simple installation and operation Special Sizes and ranges available
|
|
|
SHK-D Crosby™ Cabled Load Shackle Ranges 1tonne to 35tonne Robust construction Ideal for use in harsh environments Environmentally sealed to IP67 (higher sealings available on request)
|
|
|
PQ Platforms Four Cells The capacity of up to 6000kg Painted steel screwed on load floor (5 or 6 mm thick) Available on request in stainless steel OIML certified Shear beam load cells, nickel-plated steel with IP67 (option stainless steel IP68)
|
  |
WB Platforms Weighing Beams Engineered for weighing hoppers, conveyors, roller conveyors, tanks and cases Functioning with 4 off center load cells in aluminum (OIMLR60 certified) Power supply 15Vdc max
|
  |
Container Weighing System Real time container weighing Complies with SOLAS regulations RS485 output for integration into TOS (other outputs available) Simple to retrofit to all existing container lifting equipment
|
We provide free consultation on your load or weighing application.
If you are working on a problem, contact us at 03-7804 7533 or info@scigate.com.my
