Laser Sensor and EtherCat is very powerful for many application 1

When we talk about protocol for industry machine, automation or process line, there always have a control system which link up all necessary equipment for example, Using PLC to control motor to perform the manufacturing or other process.

Laser Displacement Sensor

Same to measurement sensor, in-order to deliver the measured value to PLC, PC, Datalogger, micro-controller or any control unit. So EtherCAT is one of the fastest, stable protocol, which is easy to integrate your system via EtherCAT.

We also honour to introduce you our Micro-Epsilon sensor which have EtherCAT protocol to make your integration much easier, and measured data more faster and stable. For our general laser triangulation sensor series as below :

NEW** ILD1900


The optoNCDT 1900 offers a unique combination of speed, size, performance and application versatility for displacement, distance and position measurements. This compact triangulation sensor achieves a high measurement accuracy and measuring rates of up to 10 kHz. The high-performance optical system generates a small light spot which enables to even detect the finest of details and structures reliably.

  • Measuring ranges (mm):
    2 | 10 | 25 | 50 | 100 | 200 | 500
  • Linearity from 1 µm
  • Adjustable measuring rate up to 10 kHz
  • Analog and digital outputs
  • Compact size with integrated electronics
  • Advanced Surface Compensation for fast adaption to changing surfaces
  • Predefined and individual presets in the web interface
  • Integrated EtherCAT interface
Download Datasheet ILD1900

We can just simply using our EtherCAT module IF1032/ETH. We also have ILD2300 high end laser triangulation sensor which can directly have Ethercat protocol without any amplifier or converter.


Connect 24 power supply and open wire of your sensor than you may use an RJ45 cable to your plc/pc to use the etherCAT interface.

Note you can use Analogue convert to EtherCAT, analogue our is a standard for all ild sensor.

For ILD2300 can direct etherCAT interface, you have the chouce below direct using D-sub or using an extended module

etherCAT interface

Setup 1 :


X stand for cable meter

Setup 2:

ILD2300-PC2300-x/csp-Rs422 extension terminal-etherCAT/CSP2008
